A Business Phone as well as an intercom Guard Unit
JDB-S98 is based on high innovative SIP technology, which is ideal for all kinds of business communication. It featuring a 10.1-inch touch screen and formed with CNC aluminum alloy body. It can work as a productivity-enhancing business phone or a feature-rich intercom guard unit.
JDB-S98 Master Phone
- Audio/Video Intercom Calls with Residents & Visitors
- Remote Door Opening for Visitors during calls
- Live View of Door Stations or IP Camera
- Record of Alarm and Call Information
- SMS Group Messaging
- Real-time Monitoring
- Simple Operation with easy-to-navigate user interface
- Crystal clear audio communication as if conversing face to face, a rich visual experience via a 10.1-inch capacitive touch screen
Physical Property
| Appearance Dimension | 385*285*45mm |
| Installation | Desktop |
| Material | Aluminum alloy and ABS plastic |
| Screen | 10.1″ |
| Resolution | 1280×800 |
| Input Operation | Touch screen |
| Audio Output | Speaker |
| Audio Input | Microphone |
| Power Consumption | < 5W |
| Working Voltage | DC18V, compatible with non-standard POE |
| Working Temperature | -35℃ – +60℃ |
| Working Humidity | 10% ~ 95% |
| OS | Android |
| CPU | 4-core ARM Cortex A7 |
| FLASH | 8G eMMC |
| SDRAM | 32bit 1GB DDR3 |
| Maximum operating frequency | 1 GHz |
| Communication Method | Wired Network |
| Functions | Video call, Remote Unlocking, Monitoring, Elevator Calling |
